The Decon E-Move Power Drive
Now you no longer have to adapt to the products. The Decon E-Move offers a variety of options to expand the functionality of a manual wheelchair and is completely adaptable to your needs. When using the pushrim, E-Move supports your starting movement in a powerful way. You save energy and easily overcome longer distances or roads and obstacles that you normally avoid.
E-Move creates personal freedom and mobility!
Unique to E-Move are the setting options, all parameters are set according to your needs. The various parameters can be easily fine-tuned. If there is an imbalance in arm strength, one-handed drive (hemiplegia), the sensitivity in pushrims (right or left), extra force forwards or backwards or the swing sensitivity, it is easy to adjust. E-Move can also be programmed in such a way that it automatically counteracts inclined surfaces (gyro function).
To be able to cover longer distances, the E-Move can be adjusted so that the wheelchair can be moved up to 20m with just one push rim grip. If you use the gyro function, the wheelchair rolls straight all the way without you having to straighten it.
Through the “2nd driving profile” option, you can easily change driving characteristics. It’s not just “indoors” or “outdoors” that the choice applies – you can apply any change!
Gyrofunction: E-Move continues to drive straight ahead even on a sloping ground. We easily forget that all sidewalks, roads or train stations are sloping and you need to compensate with one arm. Thanks to the gyro function, you do not have to think about this and your wheelchair runs straight even on a sloping ground. The Girofunction needs to be activated through the smart tune program.
One hand use (Hemiplegic): With the so called hemiplegia setting, the wheelchair can be adjusted to one-handed operation. If the system detects a starting motion on one of the wheels, it communicates with the other wheel and sets both wheels in motion in a straight line. The user can control the wheelchair using the foot.
Individual programming: E-Move can be programmed for your unique needs: Extra power (forward, backward), Swing sensitivity, Hemiplegia, Sensitivity in the drive ring, Imbalance in arm strength, Speed settings, Gyro function. With a second driving mode (optional), you can easily switch between two different driving programs, so that you always have the right support in all situations.
- Engine: AC servomotor, 24V 110W x 2
- Battery type: NiMH, 24 V, 6.7 Ah, (160.8 Wh) Li-ion, 25 V, 11.8 Ah (280 Wh)
- Weight wheel: 7 kg
- Total weight: NiMh 17 kg / Li-ion 18 kg
- Increased seat width: Max 1.8 cm/each side
- Wheel dimensions: 20”, 22”, 24”, 25” or 26”
- Air pressure: 6 Bar, 600 kPa
- Speed: 0–6 km/h
- Max range (with fully charged battery): Ca. 18km with NiMH, Ca. 30km with Li-ion, according to ISO 7176-4
- Fuse: 30A (flat)
- Max user weight: 130 kg
- Max user weight “Heavy-duty”: 150 kg
- Max gradient: 6 degrees
- CE marking: In compliance with MDR 2017/745 class 1
- Battery charger: 100 to 240V AC, 50/60Hz
- Power rating: 37V 26A (while charging)
- Charging time: Normal charging ca. 2–3 hours
